Waldent RVG Carpo V-Sensor – with 5 yr Warranty
Waldent V-Sensor RVG is an ideal solution for intraoral imaging needs with an easy-to-use sensor that allows users to capture exceptional images quickly and easily. The sensor is packed in a shock-resistant case and silicon padding offers protection from falls.
The tissue is exposed to X-ray radiation and the refracted light is captured by the sensor. The image is processed instantly and converted into digital data using Analog-to-Digital converters. This digital data is sent to the computer where the doctor can view the scan instantly.
FEATURES:
- High theoretical resolution.
- Based on CMOS (Complementary Metal-oxide Semiconductor) technology.
- Rounded- off edges.
- Easy, direct connection to personal computer for image acquisition via USB direct connector.
- Smart and powerful software.
- Durable and reliable with smooth casing.
- Automatic exposure detection.
- Less exposure time.
Key Specifications:
Hardware requirements
| CPU | ≥ 1.0GHz |
| Memory | ≥ 2GB |
| Hard Disk | ≥ 64GB |
| Display Resolution | 1024*768 or above |
| USB ports | USB2.0 ≥ 1 |
Operating system requirements
- Microsoft Windows 7/8/10 32-bit/64-bit
Technical Data
| Model | V-Sensor1/ V-Sensor2 |
| Dimensions | 19.6cm x 14.4cm x 3.4cm±1cm(Package) |
| Mechanical Size-1(mm) | 25.4*36.8*4.4 |
| Mechanical Size-2(mm) | 32*45*4.4 |
| Weight | 0.4kg ± 10% |
| Effective imaging area | V-Sensor1: 20x30mm2 |
| V-Sensor2: 26x36mm2 | |
| Power | 1.5W Max |
| Sensor technology | CMOS CsI |
| Pixel size | 20um |
| Resolution | Theoretical: 25 lp/mm |
| Measured: ＞12 lp/mm | |
| X-ray energy range | 55~100kV |
| Data interface | USB2.0 |
| Electrical safety class | Depend on the computer terminal that the sensor is connected to. |
| Protection against liquid / particular matter | IP68 (Intraoral part of sensor) |
| IPX8 (USB cables) | |
| Anti-defibrillation application part | No |
| AP/APG type equipment | Non-AP/APG type equipment |
| Â
Operating conditions |
Use: in enclosed spaces
Ambient temperature: 10°C ~ 35 °C Relative humidity: 20% ~ 90% Operating altitude < 3000m above sea level |
| Â
Transport and storage conditions |
Ambient temperature: -20 °C ~ 55 °C
Relative humidity: 20% ~ 80%, no condensation Atmospheric pressure: 70kPa~106kPa |
PACKAGING:Â Â
- 1 x V-Sensor RVG
- 1 x USB Flash Driver
- 1 x Sleeves 50pcs
- 1 x USB Extension Cable
- 1 x Sensor Mounting Bracket
Warranty:
- Manufacturer/Importer warranty of 5 Years as applicable for this product
- Warranty does not apply against any physical damage to the product
- Service and Warranty are handled by the manufacturer/importer directly for this product
